Huion – Kamvas Pro 20

Description

19.5″ Full HD Pen Display with Tilt, 8192 Pressure Levels, Battery-Free Pen, and Multi-Port Compatibility for PC and Mac

Expansive Workspace for Unbounded Creativity

With a 19.5″ display and an active area of 43.5 x 24 cm, this pen display offers a spacious canvas for your artistic projects, giving you the freedom to create with ease and precision.

Battery-Free Pen Technology for Seamless Drawing

Equipped with the PW500 pressure-sensitive, battery-free pen and advanced Electromagnetic Resonance (EMR) technology, this pen display offers a natural, uninterrupted drawing experience. With ±60° tilt detection and 8192 pressure levels, it responds accurately to your hand movements, providing a comfortable and responsive feel for creative freedom.

Eye-Friendly Anti-Glare Display

Featuring a pioneering anti-reflective screen and multilayer filter membrane, this display minimizes glare and reduces eye strain, allowing for long hours of comfortable work. The anti-reflective technology ensures a clear view of your designs without distraction, helping bring your creations to life with greater ease.

Vibrant and Accurate Color Reproduction

With 100% sRGB and 72% Adobe RGB color coverage, this display reproduces up to 16.7 million colors with impressive accuracy. It delivers vivid, true-to-life colors with minimal color distortion, ensuring that your dark and bright tones remain clear and detailed for a high-quality viewing experience.

Accelerate your work process

16 Customizable Access Keys (Press Keys) and 2 Offset Bars facilitate the work process. The Press Keys allow you to easily configure functions to change the size of the canvas, rotate the drawing, change the thickness of the brush, etc. what allows to work more quickly and efficiently.

• 19.5” widescreen HD 178 ° with high resolution 1920 x 1080, 72% NTSC rich color gamut,16.7 million colors. It offers a large space to draw. The screen shows a visual, lively and realistic experience.
• Pen without batteries, without recharging.
• 8192 Pressure Levels: 5080 LPI, 266 PPS, 25 msec. of response time.
• 8 Customizable Direct Access keys and 1 touch bar on each side: the user can configure the direct access keys according to their drawing habits in order to accelerate the workflow. Ideal for both right-handed and left-handed users.
• Tilt ± 60 °
• All ports are located on the right side of the back part, facilitating access and cable connections. Video Connections Available: HDMI, DISPLAY PORT and VGA.

Specifications

• Model: KAMVAS PRO 20
• Measures: 475 x 298 x 35mm
• Color: Black
• Weight Monitor: 910 gr.
• Screen size: 3,6 KG
• Resolution: 1920 x 1080 (16: 9)
• LCD type: IPS LCD Anti Glare
• Active Area: 434.88 x 238.68 mm
• Contrast Ratio: 1000:1
• Brightness: 250cd/m2
• Viewing Angle: 89º (H) / 89º (V), (Typ.) (CR> 10)
• Range: 72% Adobe RGB / 100% sRGB
• Colors on screen: 16,7M (8bit)
• Display: Passive electromagnetic induction
• Pencil technology: 5080 LPI
• Pressure Levels: 8192 Levels
• Tilt: ±60°
• Accuracy: 0.5mm (Center) 3mm (Corner)
• Detection height: 10 mm
• Reporting Ratio: 266 PPS
• Response Time: 25 ms
• Digital Battery-Free Pen without Batteries: PW500
• Touch Bar: 2, 1 in each side
• Press Keys: 16, 8 in each side
• Video Connectors: HDMI, DP (Display Port) and VGA
• Support of S.O. Supported: Windows 7 or later and macOS 10.12 or later

What’s in the box?

• Interactive Monitor KAMVAS PRO 20
• PW500 Interactive Battery-Free Pen
• Power adapter
• AC Adapter
• Cables HDMI and USB
• Adjustable Stand
• New Pen Holder PH05
• Cleaning Cloth
• 10 replacement nibs
• Quick Start Guide
• Artist Glove
